Adet bazlı fiyat
- 1+ adet$2.09
- 10+ adet$1.97
- 100+ adet$1.86
- 500+ adet$1.75
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Connector Type
- Header
- Shrouding
- Shrouded - 4 Wall
- Terminal
- Solder
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Depth
- 8.5mm
- Contact Materials
- Copper Alloy
- Contact Type
- Male Pin
- Contact Finish Post
- Tin
- Pitch
- 2mm
- Housing Color
- Black
- Renk
- Black
- Seri
- 957
- Insulation Color
- Black
- Uzunluk
- 17.2mm
- Row Spacing Mating
- 0.079 (2.00mm)
- Min. Çalışma Sıcaklığı
- -40°C
- Orientation
- Right Angle
- Sıra Sayısı
- 2
- Max Current Rating
- 1A
- Style
- Board to Board
- Housing Material
- Thermoplastic
- Current Rating Amps
- 1A
- Fastening Type
- Push-Pull
- Number Of Positions Loaded
- All
- Montaj
- Through Hole
- Gender
- Male
- Contact Plating
- Gold
- Akım Değeri
- 1A
- Insulation Materials
- Thermoplastic
- Parça Durumu
- Active
- Montaj Tipi
- Through Hole, Right Angle
- Maks. Çalışma Sıcaklığı
- 105°C
- Ambalaj
- Tray
- Number Of Contacts
- 10
- Pitch Mating
- 0.079 2.00mm
- RoHS Durumu
- RoHS Compliant
- Contact Length Post
- 0.118 3.00mm
- Contact Finish Thickness Mating
- Flash
- Contact Finish Mating
- Gold
- Contact Finish Thickness Post
- 39.4μin 1.00μm
