929667-01-32-I

Teknik Özellikler

Pitch Mating

0.100 2.54mm

Contact Finish Thickness Post

10.0μin 0.25μm

Contact Materials

Copper Alloy

Current Rating Amps

2.5A

Contact Plating

Gold

Row Spacing Mating

0.100 (2.54mm)

Fastening Type

Push-Pull

Montaj

Through Hole

Insulation Color

Black

Shrouding

Unshrouded

Contact Finish Mating

Gold

Style

Board to Board

Çalışma Sıcaklığı

-40°C~105°C

Montaj Tipi

Through Hole, Right Angle

Contact Length Post

0.110 2.79mm

Number Of Positions Loaded

All

Terminal

Solder

Renk

Black

Pozisyon Sayısı

64

Contact Finish Thickness Mating

10.0μin 0.25μm

Parça Durumu

Active

Material Flammability Rating

UL94 V-0

Connector Type

Header

Contact Type

Male Pin

Contact Lengthmating

0.235 5.97mm

Insulation Height

0.215 5.45mm

Nem Hassasiyeti (MSL)

1 (Unlimited)

Insulation Materials

Polybutylene Terephthalate (PBT), Polyester, Glass Filled

Contact Finish Post

Gold

Pitch

2.54mm

RoHS Durumu

RoHS Compliant

Yayın Yılı

2008

Contact Shape

Square

Seri

929

Sıra Sayısı

2

Ambalaj

Bulk
