929550-01-15-I

Teknik Özellikler

Current Rating Amps

2.5A

Contact Materials

Copper Alloy

Contact Finish Thickness Post

10.0μin 0.25μm

Pitch Mating

0.100 2.54mm

Montaj

Through Hole

Fastening Type

Push-Pull

Contact Plating

Gold

Shrouding

Unshrouded

Insulation Color

Black

Contact Finish Mating

Gold

Kurşunsuz

Contains Lead

Montaj Tipi

Through Hole, Right Angle

Housing Color

Black

Çalışma Sıcaklığı

-40°C~105°C

Style

Board to Board

Number Of Contacts

15

Number Of Positions Loaded

All

Contact Length Post

0.130 3.30mm

Renk

Black

Terminal

Solder

Housing Material

Plastic

Pozisyon Sayısı

15

Contact Finish Thickness Mating

10.0μin 0.25μm

Parça Durumu

Active

Genişlik

2.44mm

Contact Type

Male Pin

Connector Type

Header, Breakaway

Uzunluk

38.1mm

Gender

Male

Material Flammability Rating

UL94 V-0

Insulation Height

0.110 2.79mm

Contact Lengthmating

0.295 7.49mm

Pitch

2.54mm

Contact Finish Post

Gold

Insulation Materials

Polybutylene Terephthalate (PBT), Polyester, Glass Filled

Nem Hassasiyeti (MSL)

Not Applicable

RoHS Durumu

Non-RoHS Compliant

Yayın Yılı

2008

Yükseklik

5.97mm

Ambalaj

Bulk
