3517/14SF (100FT)

Teknik Özellikler

Conform To The Norm

CSA AWM I A/B FT1

Core Diameter

28AWG

Dimensions

See

A Dimension

21.1mm

Ribbon Cable Pitch

1.27mm

Version

Splice Free

Number Of Cores

14

Rated Voltage

50V

Package Contents

30.5m

Core Structure

stranded

Type Of Wire

ribbon

Cable Features

work in continuous operation up to 100 million cycles

B Dimension

16.51mm

Shield Structure

braid made of copper wires

Çalışma Sıcaklığı

-20...80°C

Kind Of Core

Cu,

Cable Structure

14x28AWG

Insulation Colour

black

Wire Insulation Material

PVC
